Features:
1. Adopt PLC microcomputer control technology. Standard printer and 7-inch color LCD touch screen.
2. Complete protection functions: The door cannot be opened during operation to ensure safe use; dual temperature protection of water temperature and air temperature; power failure protection function; water seal design of drainage pipeline to prevent reverse flow of sewage; installed with leak-proof detection, if liquid leakage is detected, The program is cancelled, the inlet valve is closed, and the drain pump is started.
Cleaning Procedure:
1. Standard procedure: Meet the general contaminant blood cleaning.
2. Quick cleaning program: Meet the cleaning of lightly polluted utensils.
3. Customized cleaning program: According to different cleaning needs, users can customize the combined cleaning program.
4. Drying program: Equipped with a high-performance drying system, which can quickly complete the drying and cleaning of various instruments.
5. Manual test procedure: Self-check the operation status of each component of the equipment.
Cleaning Racks:
Technical Parameters:
Model | BKX-CQS-120 | BKX-CQZ-120 | BKX-CQS-220 | BKX-CQS-320 |
Cleaning | Capacity(L) | 120 | 120 | 220 | 320 |
Washer Load Level | 1 | 1 | 2 | 3 |
Water Wash Power(KW) | 5 | 5 | 7 | 7 |
Water Heater Power(KW) | 3 | 3 | 4 | 4 |
MAX. Power(KW) | 6 | 6 | 9 | 9 |
Water Consumption/Step(L) | 15 | 15 | 20 | 20 |
Tank Internal Temperature(℃) | 0~95 |
Water Supply Pressure(Mpa) | Tap water: 0.3~0.8
Pure water: 0~1 |
Peristaltic Pump for Cleaning Agent | 2 |
Cleaning Agent Level Sensor | YES |
Washing Pump | Sweden 430L/min | Sweden 430L/min | Sweden 1000L/min | Sweden 1000L/min |
Standard Cleaning Racks | BKXIR36, 1pc |
Drying | Drying Function | YES |
Steam Condenser | YES |
Dry Power(KW) | 3 | 3 | 4 | 4 |
Control System and Traceability | Control System | 7" color LCD touch screen display, microprocessor |
Cleaning Program | 12 pre-set programs+4 PLC free programming |
Password Protection | YES |
Safety Emergency Button | YES |
USB Port | YES |
Integrated Printer | YES |
Online Monitor Performance of Washing | NO |
Dimension&Weight | Chamber Dimension(W*D*H,mm) | 600*630*460 | 600*630*460 | 600*610*750 | 600*610*920 |
Exterior Dimension(W*D*H,mm) | 980*740*870 | 890*800*1630 | 700*800*1850 | 700*800*2000 |
Package Dimension(W*D*H,mm) | 1150*940*1060 | 1100*970*1900 | 850*950*2250 | 850*950*2250 |
Net Weight(Host only, kg) | 190 | 260 | 290 | 310 |
Gross Weight(Host with rack, kg) | 220 | 290 | 330 | 350 |
Others | Door | Double-layered glass door, 304 stainless steel |
Safety Door Lock | YES |
Built-in RO Water Pump | YES |
Noise(dB) | <50 |
Voltage(V/Hz) | Standard: AC220V, 50Hz
Optional: AC220V, 60Hz; 110V, 50/60Hz |
Washer Disinfector (Lab Automatic Glassware Washer) BKX-CQS-120 — professional solution in the Washer Disinfector category
Washer Disinfector (Lab Automatic Glassware Washer) BKX-CQS-120 is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why Washer Disinfector (Lab Automatic Glassware Washer) BKX-CQS-120
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: Washer Disinfector (Lab Automatic Glassware Washer) BKX-CQS-120 fits easily into existing process lines and IT infrastructure.
Areas of application Washer Disinfector
Washer Disinfector solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Washer Disinfector (Lab Automatic Glassware Washer) BKX-CQS-120 allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with Washer Disinfector (Lab Automatic Glassware Washer) BKX-CQS-120 you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add Washer Disinfector (Lab Automatic Glassware Washer) BKX-CQS-120 to the cart or contact our manager. We will help integrate Washer Disinfector into existing processes without downtime and unnecessary costs.
