Features:
1. Large hollow electric heating perspective window, anti-condensation, convenient for customers to check the running condition of the box.
2. The display interface has the functions of historical data, curve, alarm record can be queried, data can be saved and exported, password lock screen protection and Chinese and English switching.
3. Humanized design of the door stop function, to protect the safety of personnel.
4. Box padding foot height adjustable, standard universal casters, easy to move the box.
5. Professionally designed side air vents to meet the oxygen requirement of samples.
Technical Parameters:
Model | BJPX-SL10-L | BJPX-SL10 | BJPX-SL20-L | BJPX-SL20 |
Display | LCD | 7 inch touch screen | LCD | 7 inch touch screen |
Circulation Mode | Forced convection |
Shaking Mode | Rotary shaking |
Drive Mode | Three axis balanced drive type |
Vibration Range | Φ26mm |
Rotating Speed | 30~300rpm |
Rotating Accuracy | ±1r/min |
Temp. Range | RT+5~60℃ | 4~60℃ |
Temp. Control Accuracy | 0.1℃ |
Temp. Uniformity | ≤±1℃(37℃） |
Temp. Fluctuation | ≤±0.5℃ |
Timing Range | 0~9999min(h) | 0~999h59min | 0~9999min(h) | 0~999h59min |
Shaking Plate Size | 413*466mm(Two layers) |
Max. Capacity | Upper Layer: 100ml*25 or 250ml*16 or 500ml*12 or 1000ml*9(Flask clamp) Lower Layer: 100ml*20 or 250ml*12 or 500ml*9 or 1000ml*6(Flask clamp) Tube Rack*2 96-well Plate*16 Clamping Rod Shaking Plate*2 |
Standard. Capacity | Upper Layer: 250ml*12 or 500ml*9 or 1000ml*6(Flask clamp) Lower Layer: Universal spring rack |
Lighting Mode | LED lamp*1 |
Sterilization Mode | UV lamp*1 |
Refrigerant | / | R134A |
Ambient Temp. | 15~35℃ |
Curve Programming | Fixed value | Fixed and multi-stage | Fixed value | Fixed and multi-stage |
Internal Material | 304 stainless steel |
Consumption | 850W | 1000W |
Power Supply | AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional) |
Internal Size(W*D*H) | 495*505*630mm |
External Size(W*D*H) | 650*785*1135mm |
Package Size(W*D*H) | 780*920*1290mm |
Net Weight | 120kg | 145kg |
Gross Weight | 140kg | 165kg |
Note:
1. The height of the container placed in the clamping rod shaking plate is no more than 215mm.
2. The total height of the tube placed in the tube rack is less than 160mm(if the tube has a stopper, the total height of the tube should be counted as the height of the stopper).
Vertical Type Shaking Incubator — professional solution in the Shaking Incubator category
Vertical Type Shaking Incubator is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why Vertical Type Shaking Incubator
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: Vertical Type Shaking Incubator fits easily into existing process lines and IT infrastructure.
Areas of application Shaking Incubator
Shaking Incubator solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Vertical Type Shaking Incubator allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with Vertical Type Shaking Incubator you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add Vertical Type Shaking Incubator to the cart or contact our manager. We will help integrate Shaking Incubator into existing processes without downtime and unnecessary costs.
