Features:
1. 3D curve shape design.
2. Special gear with low noise.
Technical Parameters:
Model | BKBM-V2S |
Capacity | 2L |
Volume of Each Capacity | 50~500ml |
Pot Quantity | 4pcs |
Running Time Range | 1~9999min |
Reciprocal Running Time | 1~999min |
Adjustable Speed
Revolution | Revolution | 35~335rpm |
Rotation | 70~670rpm |
Noise | 60±5dB |
Speed Control Mode | Frequency control |
Transmission Mode | Gear drive |
Working Mode | 2 or 4 pots can be used each time |
Maximum Sample Volume(Material+Grinding Ball) | 2/3 of the volume of the ball mill tank |
Feed Size | Soft and Crispy material<10mm, Other materials<3mm |
Out-put Granularity | Minimum Granularity can be reached to 0.1μm |
Adjusting Mode of Rotate Speed | Frequency converter with stepless speed regulation |
Consumption | 0.75KW |
Power Supply | AC110/220V±10%, 50/60Hz |
External Size(W*D*H)mm | 770*470*570 |
Package Size(W*D*H)mm | 820*540*680 |
Net Weight(kg) | 93 |
Gross Weight(kg) | 113 |
Note: Both pot and ball are optional. Fora ball mill with a capacity of 2L, if the matching mill pot specification is 25ml or 50ml, you need to purchase a base holder separately. |
Vertical Planetary Ball Mill(Square Type) — professional solution in the Ball Mill category
Vertical Planetary Ball Mill(Square Type) is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why Vertical Planetary Ball Mill(Square Type)
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: Vertical Planetary Ball Mill(Square Type) fits easily into existing process lines and IT infrastructure.
Areas of application Ball Mill
Ball Mill solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Vertical Planetary Ball Mill(Square Type) allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with Vertical Planetary Ball Mill(Square Type) you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add Vertical Planetary Ball Mill(Square Type) to the cart or contact our manager. We will help integrate Ball Mill into existing processes without downtime and unnecessary costs.
