Features：
1. Vacuum power with adjustable aspiration rate to achieve up to 15mL/S
2. Sensitive level sensor to detect when the bottle is full preventing liquid overflow
3. Fully autoclavable all system components that contact liquid
4. Easy to disassemble and clean
5. Wide range of adapters fit on the hand operator for aspirating liquids from tubes, dishes, microplates, bottles, from single channel to 8-channel tip
6. Hydrophobic filter for avoiding air contamination or liquid overflow(this feature is in the catalogue but it is not on website)
Technical Parameters:
Model | SAFEVAC |
Cat No. | 7035100000 |
Bottle Volume | 4L |
Vacuum Range | 0~600mbar |
Max. Flow | 15L/min(air) |
Max. Aspiration Speed | 17mL/s(Liquid ) |
Autoclave Component | Tube, waste bottle, operation handle |
Noise Level | ≤55dB |
Power Supply | 100~240VAC, 50/60Hz |
Dimension(W*D*H) | 180*240*450mm |
Package Size(W*D*H) | 570*420*220mm |
Weight | 3kg |
Gross Weight | 4.12kg |
Wide range of adapters fit well with tube, microplate and disk plate for various of tasks, all of which can be fully autoclaved(At 121℃ 1 bar for 20 minutes. After autoclaving the equipment must be cooled down before use ).
Adapter:
A | 8-channel tip detrusion adapter 200μl tip |
B | 8-channel needle φ1.5mm |
C | Single needle φ2.5mm, 40mm |
D | Single needle φ2.5mm, 120mm |
E | Single needle φ1.5mm, 40mm |
F | Single needle φ1.5mm, 120mm |
G | Tip detrusion adapter 200μl tip |
H | Tip detrusion adapter 1ml tip |
I | SAFEVAC Handle bracket |
J
| Handle hoop(vacuum aspirator) |
