Technical Parameters:
Model | BJPX-SVO200 | BJPX-SV200 |
Capacity | 200L |
Type | With ozone | Without ozone |
UV Ray Wavelength | 253.7/184.9nm | 253.7nm |
Sterilization Way | 2 sides of UV ray+1 side of ozone | 3 sides of UVC UV ray |
| UV Lamp Material | Quartz glass |
| Altitude | ＜2000m |
| Shelf | 500*520mm, standard 2pcs, can be optional |
| Standard Accessories | Shelf*2, doorknob*1, UV lamp*6 |
| Optional Accessories | Ozone UV lamp, wavelength is 184.9nm
|
| Consumption | 120W
|
| Power Supply | AC220V, 50/60Hz(Standard); AC110V, 50/60Hz(Optional) |
Internal Size
| 518*523*778mm
|
| External Size(W*D*H) | 750*663*1200mm |
| Net Weight | 81kg
|
Package Size(W*D*H) | 875*788*1365mm |
Gross Weight | 100kg |
Recommended UV Exposure Time:
Microorganism Species | Exposure Dose | Exposure Time |
Bacterial Propagules | ≥10000μW.s/cm2 | 10min |
Bacterial Spores | ≥100000μW.s/cm2 | 10min |
Virus | 10000μW.s/cm2≤Exposure Dose≤100000μW.s/cm2 | 10min |
Fungal Spores | General Exposure Dose≤100000μW.s/cm2 Special Exposure Dose up to 600000μW.s/cm2 | 60min |
When the target microorganism is unknown | ≥100000μW.s/cm2 | 10min |
Remarks: The suitable temperature range for ultraviolet disinfection is 20℃~40℃. If the temperature is too high or too low, the disinfection effect will be affected, and the disinfection time can be appropriately extended.
UV Sterilization Cabinet — professional solution in the Ozone UV Sterilization Cabinet category
UV Sterilization Cabinet is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why UV Sterilization Cabinet
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: UV Sterilization Cabinet fits easily into existing process lines and IT infrastructure.
Areas of application Ozone UV Sterilization Cabinet
Ozone UV Sterilization Cabinet solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing UV Sterilization Cabinet allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with UV Sterilization Cabinet you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add UV Sterilization Cabinet to the cart or contact our manager. We will help integrate Ozone UV Sterilization Cabinet into existing processes without downtime and unnecessary costs.
