Application:
Tri-gas incubator is commonly used in microbial culture, cell dynamics research, collection of mammalian cell secretions, carcinogenic or toxicological effects of various physical and chemical factors, research and production of antigens, cultivation of hybridoma cells to produce antibodies, in vitro fertilization(IVF), stem cells, tissue engineering and other research fields.
Features:
1. IR infrared sensor, using dual-channel dual-filter infrared technology.
2. ZrO2 sensor was used for oxygen concentration information acquisition.
3. The inner tank is designed with fully rounded corners and the surface is made of 304 stainless steel with electrochemical treatment.
4. The bottom water reservoir design eliminates the need for repeated water replenishment, saving time.
5. The water level alarm design alerts the operator to refill water in time, providing more comprehensive protection for the samples.
6. Equipped with a gas switching function, it can connect to two bottles of carbon dioxide gas simultaneously.
7. Equipped with leakage current and over-voltage protectors. Features over-temperature, under-temperature, over-concentration and under-concentration alarms.
Technical Parameters:
Model | BJPX-C80T | BJPX-C160T |
Type | Tri-gas series, air jacket |
Sterilization Type | 90℃ moist heat sterilization |
Capacity | 80L | 160L |
Temp. Sensor | PT100 |
Temp. Range | RT+5~60℃ |
Temp. Fluctuation | ±0.3℃(@37℃) |
Temp. Uniformity | ±0.5℃(@37℃) |
Temp. Precision | 0.1℃ |
Timing Range | 0~999h or continuous |
Display | 7-inch touch screen |
CO2 Control | IR infrared sensor with calibration certificate |
CO2 Range | 0~20vol% |
CO2 Uniformity | 0.2vol% |
CO2 Control Resolution | 0.1vol% |
O2 Sensor | ZrO2 sensor |
O2 Concentration Control Range | 3~20vol%/22~85vol% |
Ambient Temperature and Humidity | Ambient Temperature: 5~30℃(Recommendation: 25±2℃) Ambient Humidity: ≤80% |
Filter | CO2 gas filter, HEPA filter |
Power Supply | AC220V, 50/60Hz(Standard) 110V, 50/60Hz(Optional)( External transformer) Wiring Method: plug |
Consumption | 750W | 800W |
Shelves | 3pcs, adjustable |
Standard Accessories | Shelves, USB interface, CO2 relief valve, O2 relief valve, CO2 gas filter, water pump, HEPA filter |
Optional Accessory | Three-way connector |
Internal Size(W*D*H) | 410*387*505mm | 492*497*662mm |
External Size(W*D*H) | 608*707*785mm | 688*797*955mm |
Package Size(W*D*H) | 732*811*937mm | 841*1103*1141mm |
Net Weight | 65kg | 85kg |
| Gross Weight | 85kg | 120kg |
Tri-Gas CO2 Incubator 80L 160L — professional solution in the CO₂ Incubator category
Tri-Gas CO2 Incubator 80L 160L is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why Tri-Gas CO2 Incubator 80L 160L
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: Tri-Gas CO2 Incubator 80L 160L fits easily into existing process lines and IT infrastructure.
Areas of application CO₂ Incubator
CO₂ Incubator solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Tri-Gas CO2 Incubator 80L 160L allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with Tri-Gas CO2 Incubator 80L 160L you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add Tri-Gas CO2 Incubator 80L 160L to the cart or contact our manager. We will help integrate CO₂ Incubator into existing processes without downtime and unnecessary costs.
