Features：
1. Full speed function: realize fast filling and emptying.
2. Speed regulation function: The speed can be adjusted manually, or controlled through an external control interface.
3. Direction function: reversible forward and reverse.
4. Display function: display the current speed, direction and status.
5. Power-off memory function: memorize the working state before power-off(continuous work for more than 5s).
Technical Parameters：
Model | SPP-100-2J | SPP-300-2J |
Speed Range | 0.1~100rpm | 0.1~300rpm |
Speed Resolution | 0.1rpm | 0.1~99.9rpm: 0.1rpm; 100~300rpm: 1rpm |
Adjusting Method | Membrane button continuous adjustment |
Display | LED displays current speed |
Power | ≤30W | ≤75W |
Flow Range | 0.0002~380ml/min | 0.06~1140ml/min |
External Size | 254*140*140mm |
Protection Class | IP31 |
Pump Model | YZ15A |
Suitable Pump Hose | 13# 14# 19# 16# 25# 17# 18# |
Ambient Temperature | 10℃~40℃ |
Relative Humidity | ≤80% |
Atmosphere Pressure | 860hPa~1060hPa |
Power Supply | 100~240V, 50/60Hz | 100~270V, 50/60Hz |
Full Speed Function | Fast filling and emptying |
Speed Adjustable Function | Manual speed adjustment |
Direction Function | Reversible |
Display Function | Display current speed,direction and status |
Power-off memory function | Memory of working status before power failure(working continuously for more than 5 seconds) |
Standard Accessories | YZ15A pump head, 2 meters of 14# pump hose |
Optional Accessory | Foot switch |
Packing Size | 390mm*340mm*240mm |
Gross Weight | 3.3kg |
Standard Peristaltic Pump — professional solution in the Peristaltic Pump category
Standard Peristaltic Pump is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why Standard Peristaltic Pump
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: Standard Peristaltic Pump fits easily into existing process lines and IT infrastructure.
Areas of application Peristaltic Pump
Peristaltic Pump solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Standard Peristaltic Pump allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with Standard Peristaltic Pump you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add Standard Peristaltic Pump to the cart or contact our manager. We will help integrate Peristaltic Pump into existing processes without downtime and unnecessary costs.
