Soil Compaction Meter SCM-750-II

Features:

Software:

1. Showing the curve trends of each parameter, Max, Min, and Avg. Zoom in and out function.

2. Coloring the overrun area function which is visual display.

3. Save the data in EXCEL format as a copy.

4. Be able to view period of parameter or graph, and can be printed.

5. All curvilinear coordinates can be set and move, which make analysis easier.

Handset:

1. Small and exquisite, easy to carry and LCD display.

2. Collect settings: working unattended can be set to timing or manual collect data, recording and save data automatically.

3. Both AC and DC available, internal lithium battery: 8.4v 1500mAh, with function: charging protection, low voltage prompt. Also can be placed for a long time to record location.

4. Storage capacity: up to 30,000 groups in handset, and standard equipped with 4G Micro SD.

5. Data can be read on handset and also import to PC.

6. Power-off memory function: data already saved in SD card won't lose when lose power.

7. Probe to probe Consistency, handset can connect different kinds sensor by concentrator without influence on accuracy.

8. Low-power design, equipped with system monitor and protection function to avoid short circuit or interference from external.



Technical Parameters:

Model	SCM-750-II
Function	General type, display soil compaction(KPa, kg/cm2, N/cm2)directly, with data saving function
Range	0~10,000KPa; 0~100kg/cm2; 0~1,000N/cm2(switchable)
Depth	0~375mm(measuring rod is 400mm)
Accuracy	±0.5‰ FS
Position Accuracy	Three decimal ±0.05(≤50m)
Storage Capacity	Almost up to 30,000 groups in handset, and equipped with 4G Micro SD
Data-Collection Interval	5min~99hour
Working Power Supply	Battery: 8.4V lithium battery Power Adapter: 100~240V, 50/60Hz
Working Current	Stand-by power consumption 10mA, working power consumption according to the configuration
Package Size(L*W*H)	400*200*200mm
Gross Weight	3kg

Soil Compaction Meter SCM-750-II — professional solution in the Soil Testing Instrument category

Soil Compaction Meter SCM-750-II is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.

Why Soil Compaction Meter SCM-750-II

• Reliability and durability: industrial-grade design and materials withstand intense loads.
• Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
• Process efficiency: optimizing staff time and increasing productivity at every stage.
• Compliance with standards: manufactured taking into account current international requirements for the business segment.
• Ease of integration: Soil Compaction Meter SCM-750-II fits easily into existing process lines and IT infrastructure.

Areas of application Soil Testing Instrument

Soil Testing Instrument solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Soil Compaction Meter SCM-750-II allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.

Key benefits for business

Technical highlights

• Industrial reliability of components and assemblies for long-term trouble-free operation.
• Stable parameters that ensure repeatability of results and product quality.
• Energy efficiency and optimized life cycle cost of ownership.
• Compatibility with related equipment and standard data exchange protocols.

Service and support

Together with Soil Compaction Meter SCM-750-II you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
