Features:
1. High quality cold plate hot spray shell, flat surface, inner liner mirror 304 stainless steel laser welding, easy to clean.
2. The tray adopts mould injection molding, which solves the storage safety of platelets.
3. Three-dimensional air duct design with circulating fan, so that the equipment inside the forced air cooling temperature circulation, to ensure the uniformity of internal temperature.
4. High quality AC servo motor, smooth work, low noise, long service life.
5. Double-layer electric heating tempered glass door, good temperature insulation effect, effectively avoid the observation window fog, keep the box temperature constant for a long time.
6. The bottom is equipped with casters and support foot, easy to move, can adjust the level.(Not applicable to BJPX-SP05)
7. Using real-time digital signal monitoring, micro-processing PID control, information processing is fast.
Technical Parameters:
Model | BJPX-SP05 | BJPX-SP08 | BJPX-SP10 | BJPX-SP18 | BJPX-SP36 |
Display | 7-inch LCD touch screen |
Temperature Control Range | 22.0±2.0℃ |
Temperature Display Resolution | 0.1℃ |
Temperature Fluctuation | ±1.0℃ |
Temperature Uniformity | ±2.0℃ |
Mode of Oscillation | Continuous left and right reciprocation, horizontal oscillation |
Refrigerant | R134a, CFC free |
Defrost | Automatic defrost |
Alarm | Ultra-high and ultra-low temperature alarm, Oscillation device(motor) failure, Long-term door open alarm |
Oscillation Frequency | 60±5 times/min |
Oscillation Amplitude | 50±5mm |
Ambient Temperature | 5~35℃ |
Bags(200ml) | 1~10 | 1~16 | 1~20 | 1~36 | 1~72 |
Material | External Material: Cold plate thermal spraying; Internal Material: 304 stainless steel |
Consumption | 1200W | 950W | 1300W | 950W | 1500W |
Power Supply | AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer) | AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional) | AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer) |
Standard Accessory | USB interface, LED lamp, UV lamp |
Optional Accessory | Printer |
Internal Size(W*D*H) | 500*310*460mm | 485*310*569mm | 498*450*578mm | 500*337*970mm | 1018*343*895mm |
External Size(W*D*H) | 832*610*660mm | 632*600*1225mm | 645*730*1225mm | 632*620*1600mm | 1140*612*1600mm |
Package Size(W*D*H) | 930*710*810mm | 757*853*1375mm | 740*853*1375mm | 726*706*1755mm | 1235*706*1755mm |
Net Weight | 80kg | 110kg | 138kg | 135kg | 215kg |
Gross Weight | 95kg | 132kg | 160kg | 160kg | 255kg |
Platelet incubator BJPX-SP05 BJPX-SP08 BJPX-SP10 BJPX-SP18 BJPX-SP36 — professional solution in the Multifunctional Incubator category
Platelet incubator BJPX-SP05 BJPX-SP08 BJPX-SP10 BJPX-SP18 BJPX-SP36 is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why Platelet incubator BJPX-SP05 BJPX-SP08 BJPX-SP10 BJPX-SP18 BJPX-SP36
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: Platelet incubator BJPX-SP05 BJPX-SP08 BJPX-SP10 BJPX-SP18 BJPX-SP36 fits easily into existing process lines and IT infrastructure.
Areas of application Multifunctional Incubator
Multifunctional Incubator solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Platelet incubator BJPX-SP05 BJPX-SP08 BJPX-SP10 BJPX-SP18 BJPX-SP36 allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with Platelet incubator BJPX-SP05 BJPX-SP08 BJPX-SP10 BJPX-SP18 BJPX-SP36 you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add Platelet incubator BJPX-SP05 BJPX-SP08 BJPX-SP10 BJPX-SP18 BJPX-SP36 to the cart or contact our manager. We will help integrate Multifunctional Incubator into existing processes without downtime and unnecessary costs.
