Orbital and Linear Shaker

Features:

1. Double LCDs for independent display of time and speed.
2. Over speed detection and protection.

3. Different platforms and fixtures for selection.
4. Remote function provides PC control and data transmission.



Technical Parameters:

Model	SK-O330-Pro	SK-L330-Pro	SK-O180-Pro	SK-L180-Pro
Item No.	8032220100	8032120100	8032210100	8032110100
Oscillation Mode	Orbital	Linear	Orbital	Linear
Orbital Diameter	10mm	/	4mm	/
Amplitude	/	10mm	/	4mm
Max. Load(with attachment)	7.5kg		2.5kg
Speed Range	100~500rpm	100~350rpm	100~800rpm	100~350rpm
Speed And Timer Display	LCD
Time Range	1min~99h59min
Operation Mode	Continuous/timed operation
Working Environment	5~40°C, 80%RH
Protection Type	IP21
Connection Interface	RS232
Motor Type	DC motor
Motor Input	28W
Motor Output	15W
Consumption	30W
Power Supply	AC100~240V, 50/60Hz
Standard Accessory	1pc SK330.1 universal attachment		1pc SK180.1 universal attachment
External Size(W*D*H)	370*420*100mm		300*340*100mm
Package Size(W*D*H)	600*500*230mm(shaker) 450*350*250mm(accessories)		450*450*170mm(shaker) 450*350*260mm(accessories)
Gross Weight	14kg(shaker), 2.5kg(accessories)		10kg(shaker), 3kg(accessories)

Orbital and Linear Shaker — professional solution in the Shaker category

Orbital and Linear Shaker is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.

Why Orbital and Linear Shaker

• Reliability and durability: industrial-grade design and materials withstand intense loads.
• Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
• Process efficiency: optimizing staff time and increasing productivity at every stage.
• Compliance with standards: manufactured taking into account current international requirements for the business segment.
• Ease of integration: Orbital and Linear Shaker fits easily into existing process lines and IT infrastructure.

Areas of application Shaker

Shaker solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Orbital and Linear Shaker allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.

Key benefits for business

Technical highlights

• Industrial reliability of components and assemblies for long-term trouble-free operation.
• Stable parameters that ensure repeatability of results and product quality.
• Energy efficiency and optimized life cycle cost of ownership.
• Compatibility with related equipment and standard data exchange protocols.

Service and support

Together with Orbital and Linear Shaker you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
