Features:
BK-FP3536:
1. It adopts special heating furnace to ensure the safety of test.
2. The heating power is continuously adjustable. It can meet requirements of test.
3. The instrument is fully self-contained complete. The operator can do determination as long as connecting with coal gas or other civil gas.
4. With fast cooling function, it can improve test efficiency.
BK-FP3536D:
1. 8-inch IPS high-definition capacitive screen, the test data and parameters are displayed by curve in real time.
2. Automatic measurement of atmospheric pressure, automatic correction of flash point value.
3. Equipped with Bluetooth interface. The user can query test data anytime.
4. Electronic ignition, gas flame.
5. Remote automatic upgrade to obtain the latest version, remote prediction, abnormal early warning, comprehensive evaluation and maintenance of instrument operation status.
Technical Parameters:
Model | BK-FP3536 | BK-FP3536D |
Thermometer | -6°C~400°C. It is the same as thermometer ASTM 11C |
Ambient Temperature | 15°C~35°C |
Relative Humidity | ≤85% |
Consumption | ≤650W | ≤750W |
Test Flame Applicator | It applies the test flash automatically |
Heating Device | Furnace heating, no naked fire, explosion prevented. The power is adjustable from 0W to 600W | 1. Initial heating: (14~17)°C/min 2. It is (5~6)°C/min after reaching the preset flash point 20 °C |
Igniting Device | (1) Ignition source: coal gas(or civil gas) (2) Flame diameter is 3.2mm~4.8mm | Electric ignition Diameter of igniter: 0.7mm~0.8mm |
Flash Point Determination | \ | Range: Ambient to 400°C Accuracy: 0.1 °C |
Power Supply | AC220V±10%, 50Hz |
Dimension(W*D*H) | 350*290*350mm | 510*320*330mm |
Package Size(W*D*H) | 650*450*420mm | 690*500*610mm |
Gross Weight | 20kg | 35kg |
Open-Cup Flash Point Tester — professional solution in the Flash Point Tester category
Open-Cup Flash Point Tester is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why Open-Cup Flash Point Tester
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: Open-Cup Flash Point Tester fits easily into existing process lines and IT infrastructure.
Areas of application Flash Point Tester
Flash Point Tester solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Open-Cup Flash Point Tester allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with Open-Cup Flash Point Tester you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add Open-Cup Flash Point Tester to the cart or contact our manager. We will help integrate Flash Point Tester into existing processes without downtime and unnecessary costs.
