Mini PCR Workstation

Features:

1. Global exclusive.

2. Small dimension, save space, economical and convenient.

3. Automatic air speed adjustable with filter block.

4. With memory function in case of power-failure.

5. Interlock function: UV lamp and front window, UV lamp and blower, fluorescent lamp, blower and front window.

6. Audio and visual alarm: Filter replacement, window over height, abnormal air flow velocity etc.

7. Time reserve function: This can set the UV lamp and fan working time.

Reagent Preparation Area:

Positive pressure, vertical laminar flow design, equipped with primary filter and HEPA filter, which can protect the reagent preparation from external pollution and protect the reagent.

Specimen Preparation Area:

Negative pressure, the air inlet is through the front window glass door, the bottom of the operation area is returned to the air, and the top is exhausted, the upper and lower two HEPA filters are equipped to protect personnel from harmful aerosol infection and protect samples from external pollution.

Amplification Analysis Area:

Negative pressure, the air inlet is through the front window glass door, the bottom of the operation area is returnedto the air, and the top is exhausted, and the HEPA filter can protect both the personnel and the environment.

Technical Parameters:

Model		PCR1600	PCR2100	PCR2500
External Size(L*W*H)mm		1600*710*2100	2100*710*2000	2500*850*2100
Reagent Preparation Area	Operating Area Size(L*W*H)mm	440*560*510	640*560*510	640*710*610
	Pressure	Positive
	Airflow Velocity(m/s)	0.3~0.45
	Airflow Volume(m3/h)	190~290	290~430	380~560
	Exhaust Type	/
Specimen Preparation Area	Operating Area Size(L*W*H)mm	560*560*510	660*560*510	1060*710*610
	Pressure	Negative
	Airflow Velocity(m/s)	Downflow: 0.33±0.025 Inflow: 0.53±0.025
	Airflow Volume(m3/h)	210	250	400
	Exhaust Type	Type A2, 30% exhaust, 70% recirculation
Amplification Analysis Area	Operating Area Size(L*W*H)mm	440*560*510	640*560*510	640*710*610
	Pressure	Negative
	Airflow Velocity(m/s)	≥0.4
	Airflow Volume(m3/h)	≥160	≥180	≥180
	Exhaust Type	100% exhaust	100% exhaust	100% exhaust
ULPA Filter	Four, 99.999% efficiency at 0.12μm
Clean Level	Class 100(IS0 Class 5)		Class 100, Except Amplification Analysis Area
Front Window	Manual, toughened glass, anti UV
Max Opening	400mm			480mm
Noise	≤67dB(A)
Vibration	≤5μm
UV Lamp	8W*3, UV timer, UV life indicator		15W*3	30W*1, 15W*2
LED Lamp	4W*6		8W*6	8W*4, 12W*2
Illumination(lx)	≥500( Each area)		≥650(Each area)
Sockets	The load of two sockets(Each area): 500W, total 6 sockets
Display	Touch screen
Control System	Microprocessor
Visual and Audio Alarm	Filter replacement, window over height, abnormal air flow velocity
Work Surface Height	750mm
Material	Work Zone: 304 stainless steel Main Body: Cold-rolled steel with anti-bacteria powder coating
Power Supply	AC220V±10%, 50/60Hz; 110V±10%, 60Hz
Consumption	600W, total 2100W(With load)			1000W, total 2500W
Standard Accessory	LED lamp*6, UV lamp*4, Windproof plate*2(Only for PCR2100/2500), Waterproof sockets*6
Package Size(W*D*H)mm	1750*980*1400		2250*980*1400	2650*1120*1500
Gross Weight	400kg		450kg	500kg



Multifunctional Workstation Product List

Item	Name	Model	Quantity
Reagent Preparation Area	Pipette	0.5~10μl	1
	Pipette	10~100μl	1
	Pipette	100~1000μl	1
	Centrifuge	MINI-7	1
	Mixer	BJPX-VW	1
	Tips	10μl, 100μl, 1000μl	/
	Centrifuge tube	1.5ml	/
	8-strip tube	0.2ml	/
	QPCR kit	Covid-19	/
Specimen Preparation Area	Pipette	0.5~10μl	1
	Pipette	10~100μl	1
	Pipette	100~1000μl	1
	Disposable virus sampling collector(One step method)	/	/
	Tips	10μl, 100μl, 1000μl	/
	Centrifuge tube	1.5ml	/
	Centrifuge	MINI-7	1
	Mixer	BJPX-VW	1
	Nucleic acid extraction system(only for PCR2500)	BNP32 or BNP8	1
Amplification Analysis Area	QPCR	LEIA-X4	1
Other Related Equipment	Biosafety transport box	BTB-L5	1
	-25℃ freezer	BDF-25V270	1
	-86℃ freezer	BDF-86V158	1
