Colorimeter BCM-110 BCM-200

Features for BCM-110:

1. Built-in white plate parameters. No need to calibrate each time.

2. Double locating: illuminating locating and precise cross locating.

3. Switchable double measurement end face: large area stable end face and small area measurement for concave-convex end face.

4. New integrating sphere optical path design: eliminating the stray light of main optical path and auxiliary optical path.

5. Equipped with rechargeable-capacity Li-ion battery.

6. Configured CQCS3 software to realize more functions by connecting PC computure.

7. Hand-head structure, small and convenient.

Features for BCM-200:

1. Leading humanity design and convenient operation, auto white and black calibration at startup, structure design in line with ergonomics.

2. Stable measurement performance.

3. Convenient and fast locating.

4. PC software -CQCS3 software realize more function expansion.

a. The corresponding software serial number and password protection.

b. Be able to perform color difference analysis, color difference cumulative analysis, chromaticity index, color sample database management, simulating object color, etc.

5. Advanced power management design

a. Using high capacity Li-ion battery in colorimeter. It can be repeatedly charged.

b. Measuring more than 3000 times on one charge.

Technical Parameters:

Model	BCM-110	BCM-200
llluminating/Viewing Geometry	8/d
Measuring Aperture	φ4mm	φ8mm
Detector	Silicon photoelectric diode
Color Space	CIEL*a*b*C*h* CIEL*a*b*CIEXYZ
Color Difference Formula	ΔE*ab ΔL*a*b ΔE*C*h
Light Source	D65
Light Source Device	LED blue light excitation
Display	TFT LCD
Errors Between Each Equipment	≤0.80ΔE*ab	≤0.50ΔE*ab
Storage	100pcs standards, 20000pcs samples	100pcs standards, 20000pcs samples
Repeatability	Standard deviation within AE*ab 0.08 Average of 30 measurements of standard white plate
Lamp Life	3 years, more than 1 million time	5 years, more than 1.6 million time
Charging Time	8 hours-100% electricity	2 hours(8 hours for first charge)-100% electricity
Measurement Times Before Recharging	3000 times in 8 hours
Ambient Temp./Humidity Range	-10~40°C, relative humidity 0~85% without condensation
Data Interface	USB
Optional Accessory	Miniature thermal printer, Powder test box	Universal test components, Powder test box, Miniature thermal printer
Power Supply	Rechargeable li-ion battery 3.7V@3200mAh
External Size(W*D*H)	205*67*80mm	205*70*100mm
Package Size(W*D*H)	370*170*310mm
Net Weight	0.5kg	0.45kg
Volume Weight	3kg

Colorimeter BCM-110 BCM-200 — professional solution in the Colorimeter category

Colorimeter BCM-110 BCM-200 is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.

Why Colorimeter BCM-110 BCM-200

• Reliability and durability: industrial-grade design and materials withstand intense loads.
• Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
• Process efficiency: optimizing staff time and increasing productivity at every stage.
• Compliance with standards: manufactured taking into account current international requirements for the business segment.
• Ease of integration: Colorimeter BCM-110 BCM-200 fits easily into existing process lines and IT infrastructure.

Areas of application Colorimeter

Colorimeter solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Colorimeter BCM-110 BCM-200 allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.

Key benefits for business

Technical highlights

• Industrial reliability of components and assemblies for long-term trouble-free operation.
• Stable parameters that ensure repeatability of results and product quality.
• Energy efficiency and optimized life cycle cost of ownership.
• Compatibility with related equipment and standard data exchange protocols.

Service and support

Together with Colorimeter BCM-110 BCM-200 you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
