Auto ELISA Processor BIOBASE1000

Features:

1. 1 robotic arm, 1 pipetting probe(10~1000μl).

2. 2 units 96 well microplates(independent incubating).

3. 1 unit reader&washer(auto reading and washing).

Technical Parameters:

Model	BIOBASE1000
Sample Unit	Sample Racks	Standard 192 sample position (expandable, up to 384)
	Pipetting	10~1000μl
	Dispensing System	1 aspirating-dispensing probe(X-Y-Z movement)
Reagent Unit	Reagent Racks	Universal reagent position: Standard 6 universal reagent positions(expandable, up to 32);  Original reagent bottle: Standard 20 reagent bottles position(expandable, up to 80)
	Pipetting Range	10~1000μl, 1μl stepping
	Pipetting Precision	(100μl)CV≤0.5%
	Dispensing Time	5 minutes to whole 96 well microplates
Incubation Unit	Incubation	2 independent incubators
	Temperature Range	RT to 45 °C
	Temperature Accuracy	±0.5°C
Washing Unit	Washing Probes	Two line 8-nozzle manifolds
	Wash Containers	2 wash buffers 2L, 1 distilled water, 1 waste water
	Washing Residual	<2μl
Reading Unit	Reading Channels	8 independent photometric channels, mono and dichromatic reading
	Absorbance	0.0~3.0OD
	Spectral Range	400~700nm
	Optical Filters	2 standard filters(450, 630nm);  2 more on request(405nm/450nm/492nm/630nm)
Data Management	Software	Windows 7
	LIS System	Bi-direction, support HL7 protocol
	Results	Absorbance and results reviewable by software
	Printer	External optional
Working Conditions	Power Supply	AC220V±10%, 50/60Hz; 110V±10%, 60Hz, 400W
	Temperature	10~30℃
	Humidity	30~80%
Size&Weight	External Size(W*D*H)	935*665*860mm
	Net Weight	112kg
	Package Size(W*D*H)	1115*920*1398mm
	Gross Weight	160kg

Auto ELISA Processor BIOBASE1000 — professional solution in the ELISA Equipment category

Auto ELISA Processor BIOBASE1000 is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.

Why Auto ELISA Processor BIOBASE1000

• Reliability and durability: industrial-grade design and materials withstand intense loads.
• Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
• Process efficiency: optimizing staff time and increasing productivity at every stage.
• Compliance with standards: manufactured taking into account current international requirements for the business segment.
• Ease of integration: Auto ELISA Processor BIOBASE1000 fits easily into existing process lines and IT infrastructure.

Areas of application ELISA Equipment

ELISA Equipment solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Auto ELISA Processor BIOBASE1000 allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.

Key benefits for business

Technical highlights

• Industrial reliability of components and assemblies for long-term trouble-free operation.
• Stable parameters that ensure repeatability of results and product quality.
• Energy efficiency and optimized life cycle cost of ownership.
• Compatibility with related equipment and standard data exchange protocols.

Service and support

Together with Auto ELISA Processor BIOBASE1000 you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
