Features:
1. Small dimension, save space.
2. Centrifugal fan, speed adjustable. ULPA filter.
3. Motorized front window: The front window is motorized for convenient, one-hand operation.
4. Audio and visual alarm:Abnormal airflow velocity,Filter replacement,Front window at unsafe height.High flter pressure alarm.
5. Time reserve function: This can save 30 minutes waiting time after activating the cabinet and the sterlization time after experiment.
6. Remote control:Each function can be realized 6 meters away from the cabinet by remote control, which can protect the operator under emergency.
7. Large LCD display: Operators can check detailed status of the cabinet, such as inflow and downflow velocity, work area temperature and humidity, filter pressure, UV working time and filter working time, filter life indicator etc.
8. With memory function in case of power-failure.
9. Interlock function: UV lamp and front window; UV lamp and blower, LED lamp; blower and front window.
Technical Parameters:
Model | BSC-700IIA2-Z |
External Size(W*D*H) | 700*650*1920mm(700*650*1280mm without base stand) |
Internal Size(W*D*H) | 600*500*540mm |
Tested Opening | Safety height 200mm |
Max Opening | 380mm |
Inflow Velocity | 0.53±0.025m/s |
Down Flow Velocity | 0.33±0.025m/s |
ULPA Filter | Two, 99.9995% efficiency at 0.12μm, filter life indicator |
Front Window | Motorized |
Noise | ≤65dB |
UV Lamp | 15W*1 UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination |
LED Lamp | 8W*2 |
Illumination | ≥1000Lux |
Consumption | ≤500W |
Socket | Two, total load of two sockets: 500W |
Display | LCD display: exhaust filter and downflow filter pressure, filter and UV lamp working time, inflow and downflow velocity, filter life, humidity and temperature, system working time, etc |
Control System | 70% air recirculation, 30% air exhaust |
Visual and Audio Alarm | Filter replacement, window over height, abnormal air flow velocity, high filter pressure alarm, abnormal power failure |
Material | Work Zone: 304 stainless steel Main Body: Cold-rolled steel with anti-bacteria power coating |
Work Surface Height | 750mm with base stand |
Power Supply | AC220V, 50/60Hz; 110V, 60Hz |
Standard Accessory | Cabinet*1, LED lamp*2, UV lamp*2, Remote control, Drain valve*1, Waterproof socket*2, Foot swith |
Optional Accessory | Water and gas tap, Electric height adjustable base stand, Armrest, Base stand*1 |
Package Size(W*D*H) | Without Base Stand | 800*760*1470mm |
With Base stand | 800*900*1470mm |
Gross Weight | Without Base Stand | 130kg |
With Base stand | 154kg |
AC Series Class II A2 Biological Safety Cabinet BSC-700IIA2-Z — professional solution in the Biological Safety Cabinet category
AC Series Class II A2 Biological Safety Cabinet BSC-700IIA2-Z is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why AC Series Class II A2 Biological Safety Cabinet BSC-700IIA2-Z
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: AC Series Class II A2 Biological Safety Cabinet BSC-700IIA2-Z fits easily into existing process lines and IT infrastructure.
Areas of application Biological Safety Cabinet
Biological Safety Cabinet solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing AC Series Class II A2 Biological Safety Cabinet BSC-700IIA2-Z allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with AC Series Class II A2 Biological Safety Cabinet BSC-700IIA2-Z you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add AC Series Class II A2 Biological Safety Cabinet BSC-700IIA2-Z to the cart or contact our manager. We will help integrate Biological Safety Cabinet into existing processes without downtime and unnecessary costs.
