Features:
1. Self-expanding sealing ring has good sealing performance and can effectively prevent steam leakage.
2. Over-temperature and over-pressure automatic protection
3. Immersion electric heating tube, high thermal efficiency, durable stainless steel tube.
4. Equipped with a water level gauge, if the water level is too low, it will automatically stop heating(anti-dry type).
5. Electric heating or liquefied petroleum gas heating(dual-use type).
6. With self-adjustment function, temperature and time can be adjusted by itself, automatically stop heating and alarm function after sterilization(timing control type).
7. Two safety valves keep double safety(timing control type).
Technical Parameters:
Model | BKM-P18I | BKM-P18II | BKM-P18III | BKM-24I | BKM-P24II | BKM-P24II |
Type | Dual-use Type | Anti-dry Type | Timing Control Type | Dual-use Type | Anti-dry Type | Timing Control Type |
Capacity | 18L | 24L |
Max Working Pressure | 0.165MPa |
Max Working Temp. | 129℃ |
Rated Working Pressure | 0.14MPa |
Rated Working Temp. | 126℃ |
Temp. Setting | Fixed 126℃ | 105~127℃ | Fixed 126℃ | 105~127℃ |
Heating Method | Coal or electricity | Electricity | Coal or electricity | Electricity |
Sterilizing Time | Manual timing | 0~99min | Manual timing | 0~99min |
Chamber Size | Ф300*320mm | Ф280*350mm | Ф300*450mm | Ф280*460mm |
Altitude | ＜2600m |
Disinfection Tank | Φ280*240mm | Φ265*265mm | Φ280*350mm | Φ265*375mm |
Automatic Control | No | Yes | No | Yes |
Low Water Level Power Off Mode | Anti-dry burning heating pipe | Water level switch | Anti-dry burning heating pipe | Water level switch |
Standard Accessories | Sealing rubber ring*1, O-type silicone sealing ring*3, Large gasket*2, Disinfection tank*1 |
Consumption | 2KW, 1.5KW can be customized |
Power Supply | AC220V, 50/60Hz(Standard); AC110V, 50/60Hz(Optional) |
External Size(W*D*H) | 385*385*450mm | 450*340*600mm | 385*385*560mm | 450*340*710mm |
Net Weight | 15.5kg | 13.5kg | 16.5kg | 14.5kg |
Package Size(W*D*H) | 400*400*430mm | 400*400*670mm | 400*400*530mm | 400*400*770mm |
Gross Weight | 16.5kg | 14.5kg | 17.5kg | 15.5kg |
Portable Autoclave — professional solution in the Portable Autoclave category
Portable Autoclave is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why Portable Autoclave
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: Portable Autoclave fits easily into existing process lines and IT infrastructure.
Areas of application Portable Autoclave
Portable Autoclave solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing Portable Autoclave allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with Portable Autoclave you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add Portable Autoclave to the cart or contact our manager. We will help integrate Portable Autoclave into existing processes without downtime and unnecessary costs.
