Features:
1. The exterior is made of spray-coated cold-rolled steel plates, the interior is constructed with SUS304 stainless steel.
2. The 10.1-inch smart full-touch Android screen displays precision at 0.1℃.
3. Dual independent cooling systems ensure uninterrupted operation, if one system fails, the other continues to function normally. A single system can maintain long-term stable temperatures below -80℃.
4. Five-layer door seal design ensures more uniform temperature distribution and enhanced energy efficiency.
5. Featuring an integrated dual-lock design, it also includes electromagnetic locks, fingerprint locks, NFC, and other functions to ensure the security of stored items.
6. Equipped with smart IoT capabilities, it allows users to monitor the freezer's status anytime via a computer-based platform.
Technical Parameters:
Model | BDF-86V608BD |
Capacity | 608L |
Environment Temp. | 10~32℃ |
Temp. Range | -40~-86℃ |
Temp. Accuracy | 0.1℃ |
Temp. Uniformity | ≤5℃ |
Temp. Stability | ≤6℃ |
Control System | Electronic temperature control |
Display | 10.1-inch full-touch Android screen |
Sensor Type | PT100 |
Alarm | High/low temperature alarm, controller failure alarm, power outage alarm, door anomaly alarm, ambient temperature alarm, condenser blockage alarm, low battery alarm, voltage abnormality alarm |
Refrigeration Type | Direct-cooling |
Refrigerant | R600a/R1150/R14, 255g |
Defrosting Method | Manual |
Condenser&Evaporator | Condenser: finned; copper tube Evaporator: internal coil; copper tube |
Shelf | 3/Stainless steel |
Noise | ≤60dB(A) |
Outer Door | 1/Cyclopentane integral foaming |
Inner Door | 4/Cyclopentane integral foaming |
Consumption | 1200W |
Power Supply | Standard: 220V, 50Hz Optional: 220V, 60Hz; 110V, 50Hz(External transformer) |
Caster | Universal casters*4+leveling feet*2 |
Standard Accessory | RS485, USB port, test port*2(φ30mm), remote alarm |
Inner Size(W*D*H) | 620*755*1280mm |
External Size(W*D*H) | 1000*1147*1996mm |
Package Size(W*D*H) | 1150*1280*2210mm |
Net Weight | 308kg |
Gross Weight | 378kg |
-86℃ ultra-low temperature freezer — professional solution in the -86℃ Ultra-low Temperature Freezer category
-86℃ ultra-low temperature freezer is a modern business-class equipment designed for daily operation in demanding conditions. The combination of reliability, accuracy and durability makes this product the optimal choice for companies seeking consistent process quality, predictable results and reduced operating costs. The purchase price is a reasonable investment in the development and scaling of the enterprise.
Why -86℃ ultra-low temperature freezer
- Reliability and durability: industrial-grade design and materials withstand intense loads.
- Accuracy and repeatability: stable performance that reduces the risk of defects and downtime.
- Process efficiency: optimizing staff time and increasing productivity at every stage.
- Compliance with standards: manufactured taking into account current international requirements for the business segment.
- Ease of integration: -86℃ ultra-low temperature freezer fits easily into existing process lines and IT infrastructure.
Areas of application -86℃ Ultra-low Temperature Freezer
-86℃ Ultra-low Temperature Freezer solutions are widely used in manufacturing, research laboratories, construction sites, energy and agricultural sectors, pharmaceutical and food industries. Implementing -86℃ ultra-low temperature freezer allows you to increase productivity, ensure accuracy of operations and optimize resource utilization across the entire enterprise.
Key benefits for business
Return on investment
Reduced service costs and downtime, predictive budget planning, fast ROI thanks to stable operation.
Scalability
Readiness to expand capacity and integrate with other solutions without re-engineering processes.
Safety and quality control
Compliance with standards, which simplifies audits and increases the trust of customers and partners.
Technical highlights
- Industrial reliability of components and assemblies for long-term trouble-free operation.
- Stable parameters that ensure repeatability of results and product quality.
- Energy efficiency and optimized life cycle cost of ownership.
- Compatibility with related equipment and standard data exchange protocols.
Service and support
Together with -86℃ ultra-low temperature freezer you receive professional advice on selection, commissioning and personnel training. We provide warranty and post-warranty service, prompt delivery of consumables and spare parts. Our team supports projects from the procurement stage to the stable operation of the complex so that your business receives the expected result every day.
To select a package for your needs or to receive a commercial offer, add -86℃ ultra-low temperature freezer to the cart or contact our manager. We will help integrate -86℃ Ultra-low Temperature Freezer into existing processes without downtime and unnecessary costs.
